T
uning
E1 Series Servo Dr
ive Thunder Software Operati
on Manual
6-
10
HIWIN MIKROSYST
EM CORP
.
MD12UE01-
2012
Table 6.3.2
Parameter
Parameter name
Pt401
First stage first torque
command filter tim
e constant
P
t40F
Second stage secon
d torque command fi
lter frequency
Pt410
Second stage secon
d torque command
Q value
Figure 6.3.1
T
able 6.3.3
N
o.
I
tem
Description
(
1)
Tuneless stiffness leve
l
Modify tuneless
stiffness level.
(
2)
Diagram of tuneless
stiffness level
Display tuneless stif
fness level.
Follow the procedu
re below to compl
ete tunel
ess function.
1.
Select
T
ools
in the menu bar
and click
T
uneless
to open
“T
uneless” window
.
Figure 6.3.2
(1)
(2)
189
191
