Multiple Cast Setup
Multiple-cast setup interface is shown as in 753HFigure 5-13.
Figure 5-13 Multiple Cast Setup Menu
Here you can set a multiple cast group. Please refer to the following
sheet for detailed information.
· IP multiple cast group address
-224.0.0.0-239.255.255.255
-“D” address space
· The higher four-bit of the first byte=”1110”
· Reserved local multiple cast group address
-224.0.0.0-224.0.0.255
-TTL=1 When sending out telegraph
-For example
224.0.0.1 All systems in the sub-net
224.0.0.2 All routers in the sub-net
224.0.0.4 DVMRP router
224.0.0.5 OSPF router
224.0.0.13 PIMv2 router
· Administrative scoped addressees
-239.0.0.0-239.255.255.255
-Private address space
· Like the single broadcast address of RFC1918
