181
Figure 7- 50 Snapshot
Please refer to the following sheet for detailed information.
Parameter Function
Channel It is the monitor channel.
Snapshot mode
There are two modes: Timing and activation.
Frame rate
You can select from the dropdown list. The value ranges
from 1f/s to 7f/s.
Resolution
You can select from the dropdown list.
The 1-Channel 1 and the 9-channel support
D1/HD1/BCIF/CIF/QCIF.
Channel 2 to channel 8, channel 10 to channel 16 supports
CIF/QCIF.
Quality
You can select from the dropdown list. Here is for you to set
video quality.
There are six options: 10ï¼…, 30ï¼…, 50ï¼…, 60ï¼…, 80ï¼…, 100ï¼….
100% is the best quality.
Abnormity
The abnormity interface is shown as below. See Figure 7-52.
