138
After you logged in, you can see the main window. See X431H431H431HFigure 7-6X.
This main window can be divided into the following sections.
z Section 1: there are five function buttons: configuration (chapter 7.3),
search (chapter 7.4), alarm (chapter 7.5), about (chapter 7.6), log out
(chapter 7.7).
z Section 2: there are channel number and three function buttons: start
dialog and local play, refresh.
z Section3: there are PTZ (chapter 7.2.2), color (chapter 7.2.3) button and
you can also select picture path and record path.
z Section 4:real-time monitor window. Please note current preview
window is circled by a green rectangle zone.
z Section 5: Here you can view window switch button. You can also
select video priority between fluency or real-time.
îš— System monitor window switch supports full screen/1-window/4-
window/6-window/8-window/9-window/13-window/16-window/20-
window/25-window/36-window. See
X432H432H432HFigure 7-4X.
Figure 7- 4 Window Switch Menu
îš— Preview window switch. System support 1/4/8/9/16-window real-time
preview. Please you need to have the proper rights to implement
preview operation. You can not preview if you have no right to preview
the either channel. See Figure 7-5. Please note this series device does
not support this function.
