16
7. Unfasten the HDD power cable.
8. Insert the HDD power cable.
9. Use the special data cable to
connect the HDD and the SATA
port. Close the chassis and fix the
screws to secure firmly.
After completing HDD installation, please check the connection of the data
ribbon and power cord, and remount the upper cover with screws fastened.
Note
Power supply must be cut off before HDD installation
or replacement
Rack Installation
Please follow the steps listed below.
z Use twelve screws to fix the unit
z Please make sure the indoor temperature is below 35℃ (95°f).
z Please make sure there is 15cm (6 inches) space around the device to
guarantee sound ventilation.
