Honeywell CADVR-04D - Figure 7- 5 Main Menu of Web Client; Figure 7- 6 Status Information; Figure 7- 7 Control Setup; Real-Time Monitor

139
Figure 7- 5 Main Menu of Web Client
Real-time Monitor
In section 2, left click the channel name you want to view, you can see
the corresponding video in current window.
On the top left corner, you can view device IP, channel number, network
monitor bit stream.
Figure 7- 6 Status Information
On the top right corer, there are six unction buttons. See X434H434H434HFigure 7-8X.
Figure 7- 7 Control Setup
1 2 3 4 5 6
1 2 3
Section1
Section 2
Section 3
Section 5
