94
Here you can input FTP server address, port and remote directory.
When remote directory is null, system automatically create folders
according to the IP, time and channel.
User name and password is the account information for you to login the
FTP.
File length is upload file length. When setup is larger than the actual file
length, system will upload the whole file. When setup here is smaller
than the actual file length, system only uploads the set length and auto
ignore the left section. When interval value is 0, system uploads all
corresponding files.
After completed channel and weekday setup, you can set two periods
for one each channel.
Click the Test button, you can see the corresponding dialogue box to
see the FTP connection is OK or not. See
766HFigure 5-23.
Figure 5-22 FTP Setup Menu
