158
Parameter Function
Save You can click save button after you complete setup for one channel,
or you can complete the whole setups and then click save button.
Refresh Click this button to get device latest configuration information.
RS232
The RS232 interface is shown as in X461H461H461HFigure 7-31X.
Figure 7- 30 RS232 Setup Menu
Please refer to the following sheet for detailed information.
Parameter Function
RS232 There are two options: COM 01 and keyboard.
Console is to upgrade the program or debug via COM or
mini terminal software.
Function
Keyboard: COM control protocol. You can use keyboard
to control DVR via COM.
Data Bit
The value ranges from 5 to 8.
Stop Bit
There are three options: 1/2.
Baud Bit You can select corresponding baud bit here.
