7
Reverse/Pause
W
In normal playback or pause mode, click this button to reverse
playback
In reverse playback, click this button to pause playback.
Fast play

Various fast speeds and normal playback.
Slow play
Multiple slow play speeds or normal playback.
Play Next
f│
In playback mode, playback the next video
In menu setup, go to the bottom of the dropdown list.
Play previous
│W
In playback mode, playback the previous video
Shuttle
(outer ring)
In live view, it works as left/right direction key.
In playback, counter clockwise to forward and clock wise to
backward.
Jog
(inner dial)
Up/down direction key.
In playback, turn the inner dial to do frame by frame playback
when normal playback is paused.
RC indicator
ACT
Indicates if the DVR is active for remote control.
Power indicator
POWER
Indicates if the DVR is powered up
Channel indicator
1-16
Indicates whether the system is recording or not. It turns on
when the system is recording.
IR Receiver
Receives the signal from the remote controller.
HDD indicator
HDD
Indicates if the HDD is error or full.
Status indicator
STATUS
Indicates if the DVR is running.
Rear Panel
This series DVR rear panel is shown as below. See 668HFigure 2- 2.
