103
z Each channel is only corresponding with one HDD Group, while one
HDD Group can store records from several channels.
z HDD Group is only available for read-write HDD and self-defined disks,
other types of hard disks cannot be set as HDD Group.
Important:
z e-SATA also supports this function, you can manage e-SATA hard disk
as local hard disk.
z Current series software version can only set the HDD group operation
of the read-write HDDs. It is not for the redundancy HDD.
HDD Setting
Click the button “HDD Settings” at the top right corner of the 775HFigure 5-30,
system will pop up an interface as below. See
776HFigure 5-32.
The number of hard disk from 1 to 12 is shown in the “HDD No.” column.
If there is a mark
in the front of the number, it means this interface
have access to the hard disk, otherwise it does not have access to the
hard disk.
The “HDD Group” column lists the HDD Group number of current hard
disk.
When you are setting the HDD Group, please check the box of the hard
disk, and then choose the corresponding HDD Group number and save
the settings.
In
777HFigure 5-32, you can see the system has two working hard disks at the
6th and 7th position, and the 6th position hard disk belongs to HDD
Group 1, the 7th position hard disk belongs to HDD Group 2.
