172
Parameter Function
Sensitivity
There are six levels. The sixth level has the highest
sensitivity.
Region
There are six levels. The sixth level has the highest
sensitivity.
Region: If you select motion detection type, you can
click this button to set motion detection zone. The
interface is shown as in Figure 7-43. There are PAL
22X18/NTSC 22X15 zones. Right click mouse you
can go to full-screen display mode. Do remember
clicking OK button to save your motion detection
zone setup.
Period
Motion detection function becomes activated in the
specified periods.
There are six periods in one day. Please draw a
circle to enable corresponding period.
Select date. If you do not select, current setup
applies to today only. You can select all week column
to apply to the whole week.
Click OK button, system goes back to motion
detection interface; please click save button to exit.
Anti-dither
System only memorizes one event during the anti-
dither period. The value ranges from 3s to 600s.
Normal out
There is 2-channel alarm output.
Corresponding to motion detection alarm output
port(multiple choices)
Enable alarm activation function. You need to
select alarm output port so that system can activate
corresponding alarm device when alarm occurs.
Alarm latch
System can delay the alarm output for specified time
after alarm ended. The value ranges from 1s to 300s
Show message System pops up the alarm messages in the monitor
interface.
Buzzer Once you check the box here, the buzzer beeps
when an alarm occurred.
