Honeywell MX7 Tecton Reference Manual

Option Function
Report failure to reconnect
This option is Enabled (checked) by default.
The default time delay is 30 minutes. This value cannot be changed by the user.
There may be an audio or visual signal when a connection between a paired, active device fails
to re-connect. A visual signal may be a dialog box placed on the display notifying the user the
connection between one (or all) of the previously paired Bluetooth devices has failed.
Tap the X button or ok button to close the dialog box.
Possible reasons for failure to reconnect: Timeout expired without reconnecting; attempted to
pair with a device that is currently paired with another device; attempted to pair with a known
device that moved out of range or was turned off; attempted to pair with a known device but the
reason why reconnect failed is unknown.
Clear Pairing Table on Boot
This option is Disabled (unchecked) by default.
When enabled (checked), all previous paired information is deleted upon any reboot sequence
and no devices are reconnected.
When enabled (checked) "Auto Reconnect on Boot" is automatically disabled (dimmed).
Auto Reconnect on Boot
This option is Enabled (checked) by default. All previously paired devices are reconnected
upon any reboot sequence.
When disabled (unchecked), no devices are reconnected upon any reboot sequence.
Auto Reconnect
This option is Enabled (checked) by default. This option controls the overall mobile Bluetooth
device reconnect behavior.
l When Auto Reconnect is disabled (unchecked), Auto Reconnect on Boot is
automatically disabled and dimmed.
l When Auto Reconnect is disabled (unchecked), no devices are reconnected in any
situation. The status of Auto Reconnect on Boot is ignored and no devices are
reconnected on boot. The status of Clear Pairing Table on Boot controls whether the
pairing table is populated on boot.
l When Auto Reconnect is enabled (checked) and Auto Reconnect on Boot is disabled
(unchecked), devices are not reconnected on boot, but are reconnected in other
situations (example: return from out-of-range).
l When Auto Reconnect is enabled (checked) and Clear Pairing Table on Boot is enabled
(checked), devices are not reconnected on boot, but are reconnected in other situations
(example: return from out-of-range). The pairing table is cleared on boot. The status of
Auto Reconnect on Boot is ignored and the option is automatically disabled (unchecked)
and dimmed.
4-67

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
