Honeywell MX7 Tecton Reference Manual

Dimensions and Weight
Dimension
Length 8.8” | 22.3 cm
Width at Display
Width at handgrip
3.4” | 8.6 cm
2.8” | 7.1 cm
Depth at Scanner
Depth at Battery
2” | 5.1 cm
1.7” | 4.3 cm
Weight
Unit with network card, battery,
SE1524ER scanner and handle
1.6 lbs (26.1 oz) | 740g
Unit with network card, battery,
SE1524ER scanner and handstrap
1.4 lbs (22.6 oz) | 640g
Battery 4.3 oz | 122g
Handle 4 oz | 110g
Network Card 0.35 oz | 9.9g
SD Flash Card 1 oz | 28g
Environmental Specifications
Operating Temperature 14°F to 122°F (-10°C to 50°C)
Storage Temperature -4°F to 158°F (-20°C to 70°C)
ESD 8 KV air, 4kV direct contact
Freezer Operating Temperature -30°C to 60°C
Operating Humidity Up to 90% non-condensing at 104°F (40°C)
Water and Dust IEC 60529 compliant to IP65
Vibration Based on MIL Std 810D
10-2

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
