Page #136 background image
Symbologies
The Code ID drop-down box filters the available symbologies, in the Symbology drop down box, by the selected Code ID.
When a Honeywell scan engine is installed, AIM, Custom and Honeywell symbologies are displayed.
When a Hand Held Products imager scan engine is installed, AIM, Custom and HHP symbologies are displayed. HHP does
not support Symbol IDs.
When a Symbol scan engine is installed, AIM, Custom and Symbol symbologies are displayed. Symbol does not support HHP
IDs (Hand Held Products) or Honeywell IDs.
AIM Symbologies
Note: When the integrated scan engine is a Honeywell or Symbol scan engine, AIM IDs apply, but Advanced properties do
not and the Advanced button is not available.
Symbol Engine Honeywell Engine
All All
Aztec Codabar
Codabar Code 11
Code 128 Code 128
Code 39 Code 39
UPC/EAN Code 93
Code 49 EAN/UPC
Code 93 GS1 Databar
Data Matrix Interleaved 2 of 5
Interleaved 2 of 5 Matrix 2 of 5
MaxiCode MSI
MicroPDF NEC 2 of 5
PDF417 Plessey
PosiCode Str2of5
QR Code Telepen
GS1 DataBar Trioptic Code
China Post
The Data Collection Wedge does not manage mutually exclusive option selections. The user is responsible for understanding
the options that can co-exist for the data collection device. The documentation provided from the manufacturer of the
scanner/imager being managed describes the interaction between symbologies and their configurations.
4-98
