Honeywell MX7 Tecton Reference Manual

Enable Code ID
Choose an option in the Enable Code ID drop-down box:
None Disables transmission of a Code ID. The only entry in the Symbology combo box is All.
AIM ID
Transmits the AIM ID with each bar code. The combo box in the Symbology panel is populated with
the known AIM ID symbologies for the scan engine in focus, plus any configured Custom code IDs.
Honeywell ID
Transmits the Honeywell ID with each bar code. The combo box in the Symbology panel is pop-
ulated with the known Honeywell symbologies for the Honeywell laser scanner, plus any configured
Custom code IDs.
Symbol ID
Transmits the Symbol ID with each bar code. The combo box in the Symbology panel is populated
with the known Symbol ID symbologies for the Symbol laser scanner, plus any configured Custom
code IDs.
HHP ID
The imager always transmits the HHP ID with each bar code, so the Code ID is used to identify the
bar code being processed. The combo box in the Symbology control panel is populated with the
known HHP ID symbologies for that platform, plus any configured Custom code IDs.
Custom ID
Does not change the scanner’s Code ID transmission setting. The combo box in the Symbology con-
trol panel is populated with any configured Custom code IDs.
Buttons
Symbology Settings
Individually enable or disable a bar code from being scanned, set the mini-
mum and maximum size bar code to accept, strip Code ID, strip data from
the beginning or end of a bar code, or (based on configurable Barcode
Data) add a prefix or suffix to a bar code before transmission.
Ctrl Char Mapping
Define the operations the Data Collection Wedge performs on control char-
acters (values less than 0x20) embedded in bar codes.
Custom Identifiers
Defines an identifier that is at the beginning of bar code data which acts as
a Code ID. After a Custom Identifier is defined, Symbology Settings can
be defined for the identifier just like standard Code IDs.
HHP Properties
HHP Properties allows Hand Held Products Imager global (not symbology
specific) parameters to be configured. This button is only visible when a
Hand Held Products 5300 imager is installed in the MX7 Tecton.
See Also: "Data Processing Overview"
4-88

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
