Honeywell MX7 Tecton Reference Manual

Network Card Specifications
Summit 802.11 a/b/g SDIO 2.4/5.0GHz
Wireless Frequencies
2.4 to 2.4897 GHz IEEE 802.11b / 802.11g DSSS OFDM
5.0GHz IEEE 802.11a DSSS OFDM
RF Data Rates 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps
RF Power Level 64 mW (18dBm)
Channels
FCC: 1-11, 36, 40 ,44, 48, 149, 153, 157, 161
ETSI: 1-13, 36, 40, 44 ,48
Operating Temperature Same as MX7 Tecton Operating Temperature
Storage Temperature Same as MX7 Tecton Storage Temperature
Connectivity TCP/IP, Ethernet, ODI
Diversity Yes
Bluetooth
Connection No more than 32.80 feet (10 meters) line of sight
Operating Frequency 2.402 – 2.480 GHz
Bluetooth Version 2.1 + EDR
AC Wall Adapter
Input Power Switch None
Power "ON" Indicator None
Input Fusing Thermal Fuse
Input Voltage 100VAC min – 240 VAC max
Input Frequency 50 - 60 Hz
Input Connector North American wall plug, no ground
Output Connector
AC wall adapter has a 5.5mm barrel connector. This connects to the cables which tran-
sition power to the 20 pin D connector.
Output Voltage +12V, regulated
Output Current 0 Amps min, 1.25 Amps max
Operating Temperature
32 F to 100° F / -0° C to 40° C
The AC Power Adapter is only intended for use in a 25°C (77°F) maximum ambient tem-
perature environment.
Storage Temperature -40° F to 180° F / -40° C to 80° C
Humidity Operates in a relative humidity of 5 – 95% (non-condensing)
10-3

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
