Bar Code Readers
Your MX7 Tecton may be using any of the following bar code readers:
l Short Range Laser Scanner, SE955I
l Base Laser Scanner, SE955E
l Multi-Range "LORAX" Laser, SE1524ER
l Hand Held Products 2D Area Imager, 5300
l Honeywell Laser Scanner, N43XX
Note: If the SPN number on the label on the back of your MX7 Tecton ends in Rev B, your device has an integrated N43XX
scan engine. For example, SPN: MX7T9X99X9XX9X Rev B.
Note: Base Laser Scanner, 955E does not support aim mode. Any attempt to adjust the aiming beam using 955E
programming bar codes will fail. The Base Laser scanner does not decode Codablock, Code93i or Telepen
symbologies.
The MX7 Tecton can use the following external bar code readers:
l Tethered hand-held scanners are tethered to a serial port on the MX7 Tecton and are configured by scanning the engine-
specific bar codes in the scanner manufacturer's programming guide. The manufacturer's guides are usually shipped
with the bar code reader.
l Wireless hand-held Bluetooth scanners are configured by scanning the engine-specific bar codes in the scanner
manufacturer's programming guide. The manufacturer's guides are usually shipped with the bar code reader.
l The body worn Bluetooth Ring Scanner module may be using a Symbol 4400 Ring Imager or a Symbol 955 Ring
Scanner. The module and rings are configured by scanning the bar codes in the Bluetooth Ring Scanner Programming
Guide.
Return to Factory Default Settings
After scanning the engine-specific bar code to return the scanner/imager to factory default settings, the next step is to open
Start > Settings > Control Panel > Data Collection on the mobile device collecting the scanned data. Click the OK button
and close the control panel. This action will synchronize all scanner formats for your device. Another option you can use to
reset the Data Collection panel is to scan the LXEReset bar code (for Symbol and Hand Held Products scan engines) or the
N43Reset bar code (for the Honeywell Laser Scanner N43XX) located in the Integrated Scanner Programming Guide.
Engine specific bar codes are contained in the Integrated Scanner Programming Guide. They can be used to set or reset scan
engine parameters by scanning a bar code, then saving the change. Honeywell and Symbol scan engines can be programmed
using programming bar codes.
The HHP 5300 Imager engine is programmed by using the HHP Properties button on the Data Options tab and the Advanced
button available on many of the individual Symbology Settings screens to configure the Hand Held Products Imager engine.
There are no configuration bar codes for the Hand Held Products Imager.
4-80
