Honeywell MX7 Tecton Reference Manual

32 key Numeric-Alpha Keymap
l The following keypad keymap is used on an MX7 Tecton that is NOT running a Terminal Emulator. Terminal emulators
use a separate keymap.
l When using a sequence of keys that require an alpha key, first press the Alph key. Use the Shft sticky key or the Caps
key sequence (Blue+Tab) for upper case alphabetic characters.
l Pressing the Alph key forces “Alpha” mode for the 2,3,4,5,6,7,8, and 9 keys. The 1 and 0 keys continue to place a 1 and
0 into the text field.
l To create a combination of numbers and letters before pressing Enter, remember to tap the Alph key to toggle between
Alpha and Numeric mode.
l When using a sequence of keys that do not include the Alph key but does include a sticky key, press the sticky key first
then the rest of the key sequence.
l Pressing the Power key when in any sticky mode (Blue, Orange, Shift, etc) either turns the device On (when Off) or
places it in Suspend (when On).
l For those keymaps that require remapping (MAP), keys can be remapped using KeyPad (Start > Settings > Control
Panel > KeyPad).
To get this Key / Function Press these Keys in this Order
Power / Suspend Power
Field Exit (default is VK_PAUSE)
MAP = Mappable
Blue (MAP) Shft (MAP) Diamond #1
= Orange Shft (MAP)
Diamond#2
Default is Mappable
( Blue Shft (MAP)
Diamond#2
Default is Mappable
! Orange Shft (MAP)
Diamond#3
Default is Mappable
) Blue Shft (MAP)
Diamond#3
Default is Mappable
Volume Adjust Mode Orange Scan
Up Arrow
Down Arrow
Display Backlight Brightness
Adjust Mode
Blue Scan
Up Arrow
Down Arrow
Toggle Alpha Mode Alph
Toggle Blue Mode Blue
Toggle Orange Mode Orange
Toggle Shift Mode Shft
Alt Mode Alt
Control Mode Ctrl
Esc Blue Alt
Space Spc
9-13

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
