Honeywell MX7 Tecton Reference Manual

Registry
Start > Settings > Control Panel > Registry
Choose a software reload scheme.
Button Function
Load User
Defaults
When clicked, a standard load file dialog is opened, to allow the user to pick a Registry Save (.RSG) file. The
applet then copies the specified User registry file to the Active registry. The user is asked to verify a reboot,
and then the applet does a warmboot to activate the new registry.
Load User Defaults function takes 20 seconds from SD card, or 10 seconds from internal flash.
Save
User
Defaults
When clicked, a standard Save File dialog is opened, to allow the user to name the Registry Save (.RSG) file.
The applet then copies the Active registry to the specified User registry file.
Save User Defaults takes 30 seconds to save to SD card, or 10 seconds to save to internal flash.
Load
Factory
Defaults
The applet copies the Factory Default registry from the OS to the Active registry (by deleting the current
registry). The user is asked to verify a reboot, and then the applet does a restart to activate the factory default
registry. If a user password has been set, the applet warns the user that the password will be erased, and asks
the user to enter the password before the reboot is allowed.
Warmboot When clicked, the OS does a registry flush (Active registry saved to Flash registry hive), and then a warmboot.
Restart When clicked, the OS does a registry flush, and then a restart.
4-172

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
