Honeywell MX7 Tecton Reference Manual

Status LEDs
l The MX7 Tecton does not have a Bluetooth managed LED. Bluetooth activity indicators are located in the Desktop
taskbar.
l System Status LED is located at the top left of the keypad, above the Scan button.
l The Scan Status LED is located below the keypad.
l The Alpha Mode LED is located below the F4 key on the 32-key keypad (Numeric-Alpha keypad).
LED Color - Activity Indicates ...
System Status
Red - Blinking
Power fail. Replace the main battery with a fully charged main battery.
Or
Connect the MX7 Tecton to external AC power then replace the main bat-
tery with a fully charged main battery.
Red - Steady
Main Battery Low. If the main battery is not replaced with a fully charged
battery before the main battery fails, the MX7 Tecton is turned Off.
Green - Blinking Display Off. No user intervention required.
No Color
MX7 Tecton is either full on - with the display on (backlights may be
dimmed when the status LED has no color) or in Suspend - with the dis-
play off.
Scan Status
Green - Steady Good scan.
Red – Steady Scan in progress.
No color Integrated Scanner / Imager ready for use.
Amber - Steady Bar code decoder engine is storing changed parameters.
Alpha Mode
(Alph LED)
Green - Steady MX7 Tecton 32-key is in Alpha character input mode.
No color MX7 Tecton 32-key is in Numeric key input mode.
2-8

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
