Honeywell MX7 Tecton Reference Manual

Factory Default Settings
Main Tab
Device 1 Disabled
Device 2 Internal
Device 3 Disabled
Scan Mode - Continuous Disabled
Same Symbol Timeout Dimmed (1.0s)
Send Key Message (WEDGE) Enabled
COM1 Tab (External serial port)
Baud Rate 9600
Stop Bits 1
Parity None
Data Bits 8
Power on Pin 9 Disabled
Notification Tab
Enable Internal Scanner Sound Enabled
Good Scan Vibration Off
Bad Scan Vibration Off
Data Options
Enable Code ID None
Symbology Settings All
Control Character Translate All Disabled
Custom IDs Name blank
HHP Properties (Hand Held Products)
Options Disabled:
Centering
DecodeMode
LinearRange
AimTimer
LeaveLightsOn
Processing Tab
Enable buffered key output Enabled
Same buffer limit 32
Delay between buffers 75 ms
4-82

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
