Honeywell MX7 Tecton Reference Manual

Option Function
Owner
Set the mobile device owner details (name, phone, etc). Enter notes. Enable / disable
Owner display parameters. Enter Network ID for the device – user name, password,
domain.
Password Set OS access password properties for signon and/or screen saver.
PC Connection
Control the connection between the mobile device and a local desktop or laptop
computer.
Peripherals Set the touch screen and scan aperture heaters on or off, if installed.
Power Set Power scheme properties. Review device status and properties.
Regional Settings
Set appearance of numbers, currency, time and date based on country region and
language settings.
Remove Programs Select to remove specific user installed programs.
Registry
Load User Defaults, Save User Defaults, Load Factory Defaults, Warmboot and
Restart.
Stylus Set double-tap sensitivity properties and/or calibrate the touch panel.
System
Review System and Computer data and revision levels. Adjust Storage and Program
memory settings. Enter device name and description. Review copyright notices.
Volume and Sounds
Enable / disable volume and sounds. Set volume parameters and assign sound WAV
files to events.
WiFi Set the parameters for a Summit client.
About
Start > Settings > Control Panel > About
Note: The data cannot be edited by the MX7 Tecton user on these panels.
Tab Contents
Software
GUID, Windows CE Version, OAL Version, Bootloader Version, Compile Version,
Programmable Component Version(s) and Language. Language indicates localized
version.
Hardware CPU Type, Codec Type, Display, Flash memory, and DRAM memory
Versions
Revision level of software modules and .NET Compact Framework Version. LXE
Utilities, Drivers, Image, API, and Internet Explorer.
Network IP
Current IP address, MAC address, and gateway address for all network ports (radio,
ActiveSync).
Version window information is retrieved from the registry.
4-26

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
