Honeywell MX7 Tecton Reference Manual

Status Panel
Use the Status panel to view the log of previous AppLock operations and to configure which messages are to be recorded
during AppLock operation.
Status information is stored in a specific location on the storage device and in a specific logfile specified by the Administrator.
For this reason, the administrator can configure the type of status information that is logged, as well as clear the status
information.
Move the cursor to the Filename text box and either type the logfile path or tap the Browse button (the … button). The standard
Windows CE Browse dialog is displayed. After selecting the logfile from the Browse dialog, tap OK.
Note: If your Status Panel does not look like the figure shown above, you may have the Single Application version which
does not have as many options.
View
Error
Error status messages are logged when an error occurs and is intended to be used by the administrator to deter-
mine why the specified application cannot be locked.
Process
Processing status shows the flow control of AppLock components and is mainly intended for Technical Support
when helping users troubleshoot problems with their AppLock program.
Extended Extended status provides more detailed information than that logged by Process Logging.
All All messages are displayed.
Tap the Refresh button after changing from one view level to another. The filtered records are displayed, all others are not
displayed.
4-47

Honeywell MX7 Tecton Specifications

General

Display diagonal	3.5 \
Display resolution	240 x 320 pixels
Display number of colors	-
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	SD
Maximum memory card size	4 GB
Processor family	PXA 320
Processor frequency	0.806 GHz
GPS (satellite)	No
Operating system installed	Windows CE 6.0
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.0+EDR
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	5 - 100 %
Battery capacity	2200 mAh
AC adapter output current	7.4 A
Product color	Black, Blue
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), PLANET, Plessey, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Code 49, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code

Weight and Dimensions

Depth	50 mm
Width	86 mm
Height	223 mm
Weight	595 g
