Page 88 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Coaxial probes can be anchored along their length. Ensure that the probe can move freely
along its length to allow for thermal expansion.
Thermal coefficient of expansion = 16 × 10
-6
m/m-°K
Coaxial probes can be guided by a tube welded to the bottom of a tank. Make sure that
the coaxial probe can move freely to allow for thermal expansion.
Figure 3-43: Anchoring coaxial probes
