4.3 The Advanced Display Menu
Table 4-3 shows the top 3 levels of the Advanced Display menus. At each level is a
<Return> that lets you return to the previous level.
Table 4-3: Advanced Display Main Menu Structure
Level 1
Level 2
Level 3
<Exit>
N/A
N/A
Display Config
LCD Contrast
Common Setup
Screen 1-8
For details see
Table 4-5: Display Config sub-menu page 103.
Basic Config
General
Process
Measurement
Dynm Variables
4-20 mA Outputs
Set LRV
Set URV
Dev Install Date
For details see Table 4-6: Basic Configuration sub-
menu page 105.
Advance Config
Mounting
Backgrnd Capture
Probe
Volume
Reflectn Model
DAC Trim
Loop Test
HART Params
For details see
Table 4-7: Advanced Config sub-menu page 109.
Advanced Display supports the configuration of up to 8
different screens.
Monitor
Critical Diag
NonCritical Diag
Device Vars
Display Info
Comm Info
Sensor Info
Echo Stem Plot
Model Number
Licensed Options
For details see
Table 4-8: Monitor sub-menu page 114.
