Page 100 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Table 4-2: Three-Button Data Entry
Screen
Symbol
Numeric data entry
Text entry
▲
Display the high limit for this parameter.
This symbol only appears in the left-most
position of the data entry field.
Not Available
▼
Display the low limit for this parameter.
This symbol only appears in the left-most
position of the data entry field.
Not Available
▒
Terminate the numeric entry
Terminate the text entry
0 thru 9,
Minus,
Decimal
These characters are used to enter
numeric values. The minus sign only
appears in the left-most digit.
These characters can be
used to create custom
tags and unit labels
A thru Z, 0
thru 9 special
symbols
Not Available
These characters can be
used to create custom
tags and unit labels
Editing a Numeric Value
Editing a numeric value is a digit-by-digit process, starting with the left-most digit.
1. Press  to begin.
2. The Advanced Display will show the current value of the item in a pop-up
window in the middle of the screen
3. Press the  or  buttons to select the desired digit and then press  to advance to
the next digit to the right.
4. After the last digit has been entered, press  to write the new value to the
transmitter.
Selecting a new setting from a list of choices
To select a new setting for parameters that presents a list of choices (for example,
Screen Format or Display Units.):
1. Press  to begin.
2. The Advanced Display shows the current setting of the item in a pop-up
window.
3. Press  or  to scroll through the list of choices.
4. Press  to make your selection. The new selection will be stored in the
transmitter and will be displayed on the lower line, right justified.
