Page 114 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Table 4-8: Monitor sub-menu
This table describes the Advanced Display menu’s “Monitor” sub-menu. All items are Read-
Only. Refer to troubleshooting for resolutions.
<Return> Return to the Level 1 menu
FAULT: There is a problem with the Sensor.
FAULT: There is a problem with the
Communications Module (HARTor FF), There are
one of the following failures:
RAM Failure: Restart the device. If error continues,
replace the HART communication board.
ROM Failure: Reflash / reload the HART firmware.
If error continues, replace the HART
communication board.
V
CC
Failure: If the power accumulator (PA) fault is
not detected, change the HART communication
board.
FAULT: There is a problem with the interface
between the Sensor and the Electronics Module.
FAULT: There is a problem with the PV
measurement.
FAULT: A parameter has been changed that
requires a transmitter restart.
Perform transmitter restart
Yes: All menu items to Factory Mode are available.
No: The menu options end with Detail Diag.
FAULT: Sensor Internal RAM is Bad
FAULT: Sensor Internal RAM is Bad
FAULT: Sensor Flash CRC is Bad
FAULT: The Vosc measurements are out of range,
resetting the device if the problem persists, replace
the Sensor Housing.
FAULT: Sensor Power Supply 2.5V is Bad
FAULT: Sensor Power Supply 3.3V is Bad
FAULT: Power Accumulator Board is Bad
FAULT: Sensor Execution is not working as
intended
FAULT: Sensor Oscillator Control Status is Bad
Yes: Sensor is in Factory Mode
No: Sensor is in User Mode
