Honeywell SmartLine SLG 700 User Manual

Revision 8 SLG 700 SmartLine Level Transmitter User’s Manual Page 105
Disp High Limit
(FF read only)
#########
Enter the upper limit
shown on the Bar
Graph or Trend
screen.
Press  to enter
menu selection
 and  to select
number.
 to enter and shift
to next digit
Disp Low Limit
(FF read only)
#########
Enter the lower limit
shown on the Bar
Graph or Trend screen
Custom Tag
(FF read only)

Enter Custom Tag
using any
alphanumeric value up
to 14 characters long.
Press  to enter
menu selection
 and  to select
Alphanumeric
 to enter and shift
to next char.
Table 4-6: Basic Configuration sub-menu
<Return> Return to the Level 1 menu
Level 2
Level 3
Description
Action
General
<Return>
Short Tag
(HART only)
Enter Tag ID name
up to 8 characters
long.
= any
Alphanumeric value
Press  to enter menu
selection,  and  to
select number,  to
enter and shift to next
digit
Length Unit
m
cm
mm
in
ft
Select the length unit
for all level related
parameters
Press  to enter menu
selection,  and  to
select from list,  to
enter
Temp Unit
°C
°F
Select the
Temperature unit for
all Temperature-
related parameters
Velocity Unit
ft/s
m/s
in/min
m/h
ft/min
in/s
Select the Velocity
unit for all Velocity-
related parameters
Volume Unit
L
ft
3
in
3
US gal
imp gal
bbl oil
bbl liq
yd
3
m
3
Select the Volume
unit for all Volume-
related parameters
