Call up the Main Menu.
Call up a lower-level menu.
Select an item for data entry.
Confirm a data entry operation
Activate the service associated with a selected menu item.
Menu Navigation
When on a lower level menu, return to the menu above by selecting <Return>.
Alternately, the (up) and (down) buttons can be pressed simultaneously to return to the
menu above. When on the highest level menu, or when using the basic display menu,
pressing the (up) and (down) buttons simultaneously will exit the menu and return to the
PV display.
Use the and buttons to scroll through the list of menu items. Use the button to
select an item for data entry or activation. When a selection or activation is performed,
this calls up a pop-up window (Advanced Display) to allow editing. No action is taken
against a menu item until the button is pressed.
If you press button to begin data entry, you must press another button within 10
seconds or the data entry will time out and the original value of the parameter will be
preserved.
If no button presses occur within 60 seconds, menu access will time out and the
transmitter will exit the menu and return to the PV display.
Data Entry
Data entry is performed from left to right. Select a character / digit by pressing or
buttons, and then press to advance to the next character position to the right. Select
the cross-hatch character ▒ to terminate the entry or if the final character is already a
space character, just press again.
All numeric entries are clamped at the low or high limit if needed. To show the low and
high limit for a parameter, put the cursor over the left-most digit, select either the ▲ or
▼ character and press button.
