Page 94 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
FOUNDATION Fieldbus
FOUNDATION Fieldbus transmitters require a terminal voltage of 9.0V to 32.0V. See
page 170 for intrinsically safe and FISCO parameters.
Wiring Procedure
1. Ensure the loop power supply is off.
2. See Figure 3-45 for parts locations. Loosen the end cap lock using a 1.5mm
Allen wrench.
3. Remove the end cap cover from the terminal block end of the Electronics
Housing.
4. Feed loop power leads through one end of the conduit entrances on either
side of the Electronics Housing. The Transmitter accepts up to 16AWG
wire.
5. Plug the unused conduit entrance with a conduit plug appropriate for the
environment.
6. Connect the positive loop and negative loop power terminals. The
Transmitter is polarity insensitive.
7. Replace the end cap, and secure it in place.
