Page 170 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Notes:
1. Non-Intrinsically Safe Operating Voltages:
Voltage at terminals = 14.0 to 42.0 Vdc (HART / 4-20mA)
= 9.0 to 32.0 Vdc (FOUNDATION Fieldbus)
2. Intrinsically Safe Entity Parameters
a. Analog/ HART ia Entity Values:
Vmax= Ui = 30 V
Imax= Ii= 225 mA
Ci = 4 nF
Li = 0
Pi =1.1 W
b. FOUNDATION Fieldbus- ia Entity Values
Vmax= Ui = 30 V
Imax= Ii= 225 mA
Ci = 0 nF
Li = 0
Pi =1.1 W
c. FOUNDATION Fieldbus (FISCO)- Entity Values
Vmax= Ui = 17.5 V
Imax= Ii= 380 mA
Ci = 0 nF
Li = 0
Pi =5.32 W
When Installed as FISCO Ta= -50C to 45C
For ic entity, refer to the control drawing 50098941
3. For ambient and process temperature ranges and temperature classification, see section 9.5
Overfill Protection
WHG
Certificate #: Z-65.16-556. TÜV-tested and approved for overfill protection
according to the German WHG regulations
SIL 2/3
Certification
IEC 61508 SIL 2 for non-redundant use and SIL 3 for redundant use
according to EXIDA and TÜV Nord Sys Tec GmbH & Co. KG under the
following standards: IEC61508-1: 2010; IEC 61508-2: 2010; IEC61508-3:
2010.
Note: Only transmitters with SIL markings are certified for SIL
applications. – Transmitters ordered with SIL certification will signify the
SIL Level on the SLG 700 Nameplate.
China Pattern
Approval
The SLG 700 is approved according to the Law on Metrology of the
People’s Republic of China. China Pattern Approval identification numbers
2016-L262, 2016-L263, and 2016-L264.
Korean KC MSIP
Registration
SLG700 transmitters are registered under the clause 3, Article 58-2 of
Radio Waves Act. Registration # MSIP-REI-Ssi-SLG720
