Revision 8 SLG 700 SmartLine Level Transmitter User’s Manual Page 155
Table 6-1: SLG 700 Standard Diagnostics Messages
Critical Diagnostics
(Failure Conditions)
Description
Resolution
Active Diags
Read-only field.
Displays the number of status flags in
the given category which are currently
in the Active or Alarm/Warning state.
N/A
Sensor Module
Displays a status for the sensor.
N/A
Comm Module
Displays a status for the
communications module.
N/A
Sensor Comm
Displays a status for the sensor
communications.
N/A
Detail Diag
This is a read-write parameter which
can be changed if you know the
Display Password (when enabled).
N/A
Sensor Int RAM
Displays a status of the internal RAM
on the sensor.
Electronics fault.
Repower the unit to clear the
fault. If error reoccurs,
replace the sensor
electronics.
Sensor Ext RAM
Displays a status of the external RAM
on the sensor.
Sensor Flash CRC
(Cyclic Redundancy Check)
Runs a background check on bits in the
database.
Error messages communicate
differences in encountered bits in the
database.
Sensor Pwr Vosc
Failure encountered in sensing sector.
Sensor Pwr2.5V
Failure encountered in sensing sector.
Sensor Pwr 3.3V
Failure encountered in sensing sector.
Sensor Pwr Accum
Displays a status of the power
accumulator.
Electronics fault.
Repower the unit to clear the
fault. If error reoccurs,
replace the sensor
electronics.
Sensor Execution
Displays a status of sensor
performance.
Sensor Oscillator
Failure encountered in sensing sector.
Factory Mode
Indicates the mode in which the
transmitter is currently running.
Factory mode allows users to run
HART commands.
Execute HART commands to
exit factory mode.
