Page 156 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Non-Critical Diagnostics
(Warning Conditions)
Displays a numeric value of the current
count of non-critical status bits that
have been set.
Displays a status of the power voltage.
Ensure the voltage on the
terminals are within
operational specifications.
Displays a status of the sensor
electronics.
Bring the sensor within range
and reset the power.
Displays a status of the Loop PV is
within or outside the configured URV
and LRV.
PV Out of Range
Any of the following
conditions can cause this
failure:
1. Sensor Overload or Fault
or Redundant
Characterization
Calculation Error.
2. Check range and, where
required, replace
transmitter with one that
has a wider range.
Sensor may have been
damaged.
3. Check the transmitter for
accuracy and linearity.
4. Replace the sensor and
recalibrate, where
required.
Displays a status of the temperature of
the sensor electronics.
If the temperature is outside
the configured range, bring
the temperature within the
range and reset or repower.
Displays a status of the quality of the
signal strength.
Read the echo curve and
configure the algorithm and
the dielectric constant.
Displays a status of the quality of the
signal.
Upper Product Signal Strength
Displays the status of the strength of
the signal monitoring the upper
product.
Upper Product Signal Quality
Displays the status of the quality of the
signal monitoring the upper product.
Lower Product Signal Strength
Displays the status of the strength of
the signal monitoring the lower product.
Lower Product Signal Quality
Displays the status of the quality of the
signal monitoring the upper product.
Bulk Distance High Zone
The distance within the upper blocking
range.
Theses parameters display
physical locations within the
container where
measurements are not
accurate.
Bulk Distance Low Zone
The distance within the lower blocking
range.
