Honeywell SmartLine SLG 700 - Flange Pressure Ratings; Material Exposed to Tank Atmosphere

Page 90 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Flange pressure ratings
ANSI:
316/316L Flanges according to ANSI B16.5
SLG720: Max. 200
o
C/40 bar (392
o
F/580 psig).
SLG726: Up to Class 1500.
C276 > 316L Flanges according to ANSI B16.5
SLG720: Max. 200
o
C/40 bar (392
o
F/580 psig)
EN:
316/316L Flanges according to EN 1092-1, material group 14E0.
SLG720: Max. 200
o
C/40 bar (392
o
F/580 psig).
SLG726: Up to PN250.
C276>316L Flanges according to EN 1092-1, material group 14E0.
SLG720: Max. 200
o
C/40 bar (392
o
F/580 psig).
Fisher and Masoneilan:
316/316L Flanges according to ANSI B16.5.
SLG720: Max. 200
o
C/40 bar (392
o
F/580 psig).
SLG726: Up to Class 600.
Material Exposed to Tank Atmosphere
SLG720
316L (UNS 31603), PTFE, and O-ring materials (FKM, FFKM, EPDM,
or NBR).
SLG720
C-276 Option (HASTELLOY): Alloy C-276 (UNS N10276), PTFE, and
O-ring materials (FKM, FFKM, EPDM, or NBR).
SLG726
High Temperature Region: 316L (UNS 31603), Ceramic (Al2O3),
BOROFLOAT® 33 Glass.
Low Temperature Region: PEEK GF30, Gold over Nickel plate on
Brass Alloy 360, Gold over Nickel plate on Beryllium Copper Alloy
172 HT, and seal materials (Gold Plated Alloy 718 or Silver with Gold
underlay plated 17-4PH).
