Honeywell SmartLine SLG 700 User Manual

Revision 8 SLG 700 SmartLine Level Transmitter User’s Manual Page 37
Tools
Required tools depend on options ordered.
For this item
(Model number signifiers)
Use this tool
M3 set screw for Coaxial coupler (SCA ACA)
AF
1
1.5 mm Allen key
M4 set screw for Electronics Housing rotation
AF 2.0 mm Allen key
M5 set screw for Wire probe end weight (SWA,
SWB)
AF 2.5 mm Allen key
Rod probe (8mm) (SRA, SRH, SRJ, SCA)
AF 7 mm wrench
Rod probe and nut (12 mm) (SRB, SRM, SRN)
AF 10 mm wrench
Rod probe (16mm) (SRK, SRL, SCB)
AF 14 mm wrench
Saturated steam reference rod (22 mm)
AF 20 mm wrench
Probe nut (8mm) (SRA, SRH, SRJ, SCA)
AF 8 mm wrench
Probe nut (16mm) (SRK, SRL, SCB)
AF 14 mm wrench
Saturated steam nut (22 mm)
AF 20 mm wrench
Centering disk bolt (Wire probe)
AF 17 mm wrench
Mounting thread ¾” and 1” (SLG720) (xx7A, xx1A)
AF 40 mm wrench
Mounting thread 1-½” (SLG720) (xx5A)
AF 50 mm wrench
Mounting thread 2” (SLG720) (Nx2A)
AF 60 mm wrench
Mounting thread 1-½”, 2” (SLG726) (NS5A)
AF 60 mm wrench
Coaxial probe outer process connector (SCA SCB)
Process compatible thread locking
compound is recommended (for
example, Loctite 242)
Coaxial probe outer process connector (SCA, ACA)
Retaining ring pliers for internal
diameter 20 mm
Coaxial probe outer process connector (SLG726 /
SCB)
Retaining ring pliers for internal
diameter 40 mm
Rod and coaxial probe cut to length
Metal saw
Wire probe cut to length
Saw or bolt cutter
Drill hole in coaxial outer tube (SLG720)
Drill and 6.0 mm drill bit
Remote mounting transmitter to bracket
Phillips screwdriver
1
AF means across face referring to tool size.
