Page 106 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Process
<Return>
Measured Prod
Single Liquid
2 Liq Flooded
2 Liq NonFlood
Saturated Steam
SingleLiqLowDC
Select the Measured
Product from the List
Press  to
enter
menu
selection,
 and  to
select
from list, 
to enter
Vapor DC
###.###
Applicable for single and
two liquids, non-flooded
only. If its value greater
than UP/LP DC Warning
message will be
displayed
Product DC
Applicable only for solid
and single liquid
measured products.
If its value is less than
Vapor DC, a warning
message will be
displayed
Upper Prod DC
###.###
Applicable only for two
liquid measured
products.
If its value is less than
Vapor DC or greater
than LP DC a warning
message will be
displayed
Press  to
enter
menu
selection,
 and  to
select
from list, 
to enter
Lower Prod DC
Applicable only for two
liquid measured
products.
If LP DC - UP DC <10 a
Warning message will be
displayed
Vapor Atten
###.###
Applicable for single and
two liquids, non-flooded
only. Attenuation of
vapor.
Product Atten
###.###
Attenuation of product,
single liquids only
Lower Prod Atten
###.###
Attenuation of lower
product, two liquids only
Upper Prod Atten
###.###
Attenuation of upper
product, two liquids only
Max Fill Rate
###.###
Maximum rate of filling or
emptying.
Measurement
<Return>
Sensor Height
###.###
Range 0 to 100m
Press  to
enter
menu
selection,
 and  to
select
from list, 
to enter
Max Product Level
Level Offset
Range -100 to 100m
Echo Lost Time
###.###
Time in seconds until a
PV Bad fault occurs after
the echo is no longer
detected.
