Revision 8 SLG 700 SmartLine Level Transmitter User’s Manual Page 53
Probe Length 1.0m to 2.0m
Step
Action
1
Fully thread the nut onto the central conductor of the process connector. Place a
lock washer between the locknut and the first rod segment and torque the nut
against the rod segment and lock washer to secure the connection.
Note: Tighten rod connection point to the following torque:
SLG720 6.0Nm (4.4ft-lbs)
2
Slide a spacer onto first rod. Connect the rod "end" segment to first rod using a
stud and lock washer. Refer to Detail A of Figure 3-13: SLG720 Coaxial probe
assembly (single outer tube depicted).
Note: Tighten rod connection point to the following torque:
SLG720 6.0Nm (4.4ft-lbs)
3
Slip the coaxial outer tube over the rod and tighten to the process connector.
Note: Tighten connection point to the following torque:
SLG720 30Nm (22ft-lbs)
It is recommended that a process compatible thread locking compound
(i.e. Loctite 242) be used on the outer conductor threaded joints.
4
Insert an end spacer into the end of tube. Align the holes in the end spacer with
the holes in the outer tube and insert the 2 locking pins. Refer to Detail B of Figure
3-13: SLG720 Coaxial probe assembly (single outer tube depicted).
Probe Length ˃ 2.0m
Step
Action
1
Fully thread the nut onto the central conductor of the process connector. Place
a lock washer between the locknut and the first rod segment and torque the
nut against the rod segment and lock washer to secure the connection.
Note: Tighten rod connection point to the following torque:
SLG720 6.0Nm (4.4ft-lbs)
2
Connect the rod segment to first rod using a spacer, a stud and lock washer
as shown in Detail A of Figure 3-13: SLG720 Coaxial probe assembly (single
outer tube depicted).
Note: Tighten rod connection point to the following torque:
SLG720 6.0Nm (4.4ft-lbs)
3
Slip the “starter” coaxial outer tube over the rod and spacers and secure to the
process connector using the M20x1 thread.
Note: Tighten connection point to the following torque:
SLG720 30Nm (22ft-lbs)
It is recommended that a process compatible thread locking compound
(i.e. Loctite 242) be used on the outer conductor threaded joints.
4
Insert an end spacer into the end of tube. Align the holes in the end spacer
with the holes in the outer tube and insert the 2 locking pins. Refer to Detail B
of Figure 3-13: SLG720 Coaxial probe assembly (single outer tube depicted).
