Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/99124
2.45 ON/OFF Function Block,
continued
Configuration Parameters,
continued
RANGE/LIMIT
TAB, continued
Table 2-36 Range/Limit Tab Configuration Parameters
Properties
Function
Parameter Index# Parameter Description Value or Selection
Ranging PV High
range
0 PV High Range Value -99999 to 99999
PV Low
Range
1 PV Low Range Value -99999 to 99999
Display Decimal
Places
N/A Number of digits to display after
decimal point.
0 to 5
Units
N/A Text to display for EU 4 characters
DEV Bar
Range (EU)
N/A Deviation Bar Range on the
Operator Interface
-99999 to 99999
Limiting SP High Limit
6 Setpoint High Limit Value -
prevents the local and remote
setpoints from going above the
value set here.
-99999 to 99999
SP Low limit
7 Setpoint Low Limit Value -
prevents the local and remote
setpoints from going below the
value set here.
-99999 to 99999
SP Rate
Down
9 Setpoint Rate Down value -
when making a setpoint
change, this is the rate at which
setpoint will change from the
original setpoint
down
to the
new one.
0 (off) to 9999 (eu/min)
SP Rate Up
10 Setpoint Rate Up value - when
making a setpoint change, this
is the rate at which setpoint will
change from the original
setpoint
up
to the new one.
0 (off) to 9999 (eu/min)
Continued next page
