Honeywell UMC800 Reference Guide

Function Blocks
3/99 Function Block Reference Guide 217
2.74 TPSC (3POS) Function Block,
continued
Configuration Parameters,
continued
Table 2-58 General Tab Configuration Parameters
Properties Group Parameter Index# Parameter
Description
Value or Selection
Block Order
N/A Execution Order
Read Only. See “Configure’ Menu,
”Execution Order” to change.
Tag Name
N/A 8 character tag name
Descriptor
N/A Block descriptor
Control Direction
N/A Control Action
DIRECT
- Proportional action
causes output to
increase
as
process variable increases.
REVERSE
- Proportional
action causes output to
decrease
as process variable
increases.
SP Tracking
N/A Setpoint Tracking
None
Track PV
When control mode
is “manual”, local
setpoint
tracks process variable.
Track RSP
When
setpoint
is
“remote
setpoint
”, local
setpoint
tracks remote
setpoint
.
Continued next page
