Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/99218
2.74 TPSC (3POS) Function Block,
continued
Table 2-58 General Tab Configuration Parameters,
continued
Properties Group Parameter Index# Parameter
Description
Value or Selection
Start/Restart
Initial Mode
N/A Control Mode and
Setpoint at
NEWSTART
Newstart is the first
scan cycle following
the cold start of the
controller
MAN LSP
Manual control and
last local
setpoint.
AUTO LSP
Automatic control and
last local
setpoint
.
AUTO RSP
Automatic control and
remote
setpoint
.
Man LSPonly
Manual control
and local
setpoint
only.
Auto LSPonly
Automatic control
and local
setpoint
only*.
Auto RSPonly
Automatic control
and remote
setpoint
only*.
*These modes will override the
configured POWER UP MODE.
Power Up
Mode
N/A Control Mode and
Setpoint at power up
MAN LSP
Manual control and
last local
setpoint.
AM LSP
Same control mode
(auto or manual) and
last local setpoint.
AM LR Same control mode (auto
or manual) and setpoint
(local or remote) as at
power-down.
Power Up
Out
N/A Output at Power up
LAST OUT
Same as at power
down.
FAILSAFE
Failsafe output value.
Failsafe out
Failsafe
Output
13 Failsafe Output Value
Selections:
0%
100%
