Honeywell UMC800 Reference Guide

Function Blocks
3/99 Function Block Reference Guide 221
2.74 TPSC (3POS) Function Block,
continued
Configuration Parameters,
continued
RANGE/LIMIT
TAB, continued
Table 2-60 Range/Limit Tab Configuration Parameters
Properties Group Parameter Index# Parameter Description Value or Selection
Ranging PV High
range
3 PV High Range Value -99999 to 99999
PV Low
Range
4 PV Low Range Value -99999 to 99999
Display Decimal
Places
N/A Number of digits after decimal
point for display
0 - 5
Units
N/A Engineering units for display up to 4 characters
` DEV Bar
Range (EU)
N/A Deviation Bar Range on the
Operator Interface
-99999 to 99999
Limiting SP High
Limit
10 Setpoint High Limit Value -
prevents the local and remote
setpoints from going above the
value set here.
-99999 to 99999
SP Low
Limit
11 Setpoint Low Limit Value -
prevents the local and remote
setpoints from going below the
value set here.
-99999 to 99999
Out High
Limit
25 Autotuning Output High Limit
Value - is the highest value of
the output beyond which the
motor no longer affects the
process.
0 to 100%
Out Low
limit
26 Autotuning Output Low Limit
Value - is the lowest value of the
output beyond which the motor
no longer affects the process.
0 to 100%
SP Rate
Down
34 Setpoint Rate Down value -
when making a setpoint change,
this is the rate at which setpoint
will change from the original
setpoint
down
to the new one.
0 (off) to 9999
(eu/min)
SP Rate Up
35 Setpoint Rate Up value - when
making a setpoint change, this is
the rate at which setpoint will
change from the original setpoint
up
to the new one.
0 (off) to 9999
(eu/min)
