Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/9916
2.5 AI Function Block,
continued
Table 2-3 Input Types and Ranges
Input
Type
Range Input
Type
Range
Thermocouple Input Types Thermocouple Input Types (cont)
J –50 to 150ºC S –20 to 1760ºC
J –58 to 302ºF S –4 to 3200ºF
J 0 to 400ºC T –50 to 150ºC
J 32 to 752ºF T –58 to 302ºC
J –200 to 870ºC T 0 to 150ºC
J –328 to 1598ºF T 32 to 302ºF
L –50 to 150ºC T 50 to 150ºC
L –58 to 302ºF T 122 to 302ºF
L 0 to 400ºC T –200 to 400ºC
L 32 to 752ºF T –328 to 752ºF
L –200 to 870ºC T –90 to 240ºC
L –328 to 1598ºF T –130 to 464ºF
K 0 to 400ºC U –50 to 150ºC
K 32 to 752ºF U –58 to 302ºF
K 0 to 800ºC U 0 to 150ºC
K 32 to 1472ºF U 32 to 302ºF
K 0 to 1200ºC U 50 to 150ºC
K 32 to 2192ºF U 122 to 302ºF
K –200 to 1370ºC U –200 to 400ºC
K –328 to 2498ºF U –328 to 752ºF
N 0 to 400ºC NiMo 0 to 1400ºC
N 32 to 752ºF NiMo 32 to 2552ºF
N 0 to 800ºC W_W26 –20 to 2320ºC
N 32 to 1472ºF W_W26 –4 to 4208ºF
N 0 to 1200ºC W5W26 –20 to 2320ºC
N 32 to 2192ºF W5W26 –4 to 4208ºF
N –200 to 1300ºC PR20-40 0 to 1800ºC
N –328 to 2372ºF PR20-40 32 to 3272ºF
R –20 to 1760ºC B 40 to 1820ºC
R –4 to 3200ºF B 104 to 3308ºF
S 0 to 1600ºC MoCo* 0 to 1400ºC
S 32 to 2912ºF MoCo* 32 to 2552ºF
*Nickel/Nickel Moly, 1990 temp. Standard
