Honeywell UMC800 Reference Guide

Function Blocks
3/99 Function Block Reference Guide 17
2.5 AI Function Block,
continued
Table 2-3 Input Types and Ranges
, continued
Input
Type
Range Input
Type
Range
RTD Input Types Linear Input Types
Pt100 –50 to 150ºC mV 0 to 10
Pt100 –58 to 302ºF mV –10 to 10
Pt100 0 to 100ºC mV 0 to 20
Pt100 32 to 212ºF mV –20 to 20
Pt100 0 to 200ºC mV 0 to 50
Pt100 32 to 392ºF mV –50 to 50
Pt100 0 to 400ºC mV 10 to 50
Pt100 32 to 752ºF mV 0 to 100
Pt100 –200 to 800ºC mV –100 to 100
Pt100 –328 to 1472ºF mV 0 to 500
Pt100 –90 to 240ºC mV –500 to 500
Pt100 –130 to 464ºF mA 0 to 20
JIS –50 to 150ºC mA 4 to 20
JIS –58 to 302ºF V 0 to 1
JIS 0 to 100ºC V –1 to 1
JIS 32 to 212ºF V 0 to 2
JIS 0 to 200ºC V –2 to 2
JIS 32 to 392ºF V 0 to 5
JIS 0 to 400ºC V –5 to 5
JIS 32 to 752ºF V 1 to 5
JIS –200 to 500ºC V 0 to 10
JIS –328 to 932ºF V –10 to 10
Ni50 –80 to 320ºC
Ni50 –112 to 608ºF
Ni508 –80 to 150ºC
Ni508 –112 to 302ºF
Cu10 –20 to 250ºC
Cu10 –4 to 482ºF
Ohms 0 to 200
Ohms 0 to 2000
