Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/99126
2.45 ON/OFF Function Block,
continued
Configuration Parameters,
continued
ALARMS
TAB, continued
Table 2-37 Alarm Tab Configuration Parameters
Properties
Function
Parameter Index# Parameter Description Value or Selection
Alarm 1 Setpoint 1
14
Alarm 1 Setpoint 1 Value
- this
is the value at which you want
the alarm type chose below to
activate
-99999 to 99999 in
Engineering Units
Type
N/A Alarm 1 Setpoint 1 Type
- select
what you want Alarm 1 Setpoint
1 to represent.
Selections:
NO ALARM
PV_HIGH
PV_LOW
DEV_HIGH
DEV_LOW
SP_HIGH
SP_LOW
OUT_HIGH
OUT_LOW
Setpoint 2
15 Alarm 1 Setpoint 2 Value Same as
Alarm 1 Setpoint 1
Type
N/A Alarm 1 Setpoint 2 Type Same as
Alarm 1 Setpoint 1
Alarm 2 Setpoint 1
16 Alarm 2 Setpoint 1 Value Same as
Alarm 1 Setpoint 1
Type
N/A Alarm 2 Setpoint 1 Type Same as
Alarm 1 Setpoint 1
Setpoint 2
17 Alarm 2 Setpoint 2 Value Same as
Alarm 1 Setpoint 1
Type
N/A Alarm 2 Setpoint 2 Type Same as
Alarm 1 Setpoint 1
Alarm
Hysteresis
%
22 Alarm Hysteresis in % 0 to 5 %
Continued next page
