Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/9974
2.23 FGEN Function Block,
continued
Configuration Parameters,
continued
Table 2-22 Function Generator Configuration Parameters
Properties Group Parameter Index# Parameter Description Value or Selection
Block Block Order
Read Only. See
“Configure’ Menu,
”Execution Order” to
change.
Breakpoints X1 0
X-value at Input Breakpoint 1 -99999 to 999999
X2 1
X-value at Input Breakpoint 2 -99999 to 999999
X3 2
X-value at Input Breakpoint 3 -99999 to 999999
X4 3
X-value at Input Breakpoint 4 -99999 to 999999
X5 4
X-value at Input Breakpoint 5 -99999 to 999999
X6 5
X-value at Input Breakpoint 6 -99999 to 999999
X7 6
X-value at Input Breakpoint 7 -99999 to 999999
X8 7
X-value at Input Breakpoint 8 -99999 to 999999
X9 8
X-value at Input Breakpoint 9 -99999 to 999999
X10 9
X-value at Input Breakpoint 10 -99999 to 999999
X11 10
X-value at Input Breakpoint 11 -99999 to 999999
Y1 11
Y-value at Output Breakpoint 1 -99999 to 999999
Y2 12
Y-value at Output Breakpoint 2 -99999 to 999999
Y3 13
Y-value at Output Breakpoint 3 -99999 to 999999
Y4 14
Y-value at Output Breakpoint 4 -99999 to 999999
Y5 15
Y-value at Output Breakpoint 5 -99999 to 999999
Y6 16
Y-value at Output Breakpoint 6 -99999 to 999999
Y7 17
Y-value at Output Breakpoint 7 -99999 to 999999
Y8 18
Y-value at Output Breakpoint 8 -99999 to 999999
Y9 19
Y-value at Output Breakpoint 9 -99999 to 999999
Y10 20
Y-value at Output Breakpoint 10 -99999 to 999999
Y11 21
Y-value at Output Breakpoint 11 -99999 to 999999
Clear All Button
Click on button to clear all breakpoint values
.
