Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/9956
2.15 CARB Function Block,
continued
Configuration Parameters,
continued
ALARMS
TAB, continued
Table 2-16 Alarms Tab Configuration Parameters
Properties Group Parameter Index# Parameter Description Value or Selection
Alarm 1 Setpoint 1
17
Alarm 1 Setpoint 1 Value
-
this is the value at which you
want the alarm type chosen
below to activate
-99999 to 99999 in
Engineering Units
Type
N/A Alarm 1 Setpoint 1 Type -
select what you want Alarm 1
Setpoint 1 to represent.
Selections:
NO ALARM
PV_HIGH
PV_LOW
DEV_HIGH
DEV_LOW
SP_HIGH
SP_LOW
OUT_HIGH
OUT_LOW
Setpoint 2
18 Alarm 1 Setpoint 2 Value
Same as
Alarm 1
Setpoint 1
Type
N/A Alarm 1 Setpoint 2 Type
Same as
Alarm 1
Setpoint 1
Alarm 2 Setpoint 1
19 Alarm 2 Setpoint 1 Value
Same as
Alarm 1
Setpoint 1
Type
N/A Alarm 2 Setpoint 1 Type
Same as
Alarm 1
Setpoint 1
Setpoint 2
20 Alarm 2 Setpoint 2 Value
Same as
Alarm 1
Setpoint 1
Type
N/A Alarm 2 Setpoint 2 Type
Same as
Alarm 1
Setpoint 1
Alarm
Hysteresis
Hysteresis
25 Alarm Hysteresis in % 0 to 5%
