Honeywell UMC800 Reference Guide

Function Blocks
Function Block Reference Guide 3/99148
2.50 PID Function Block,
continued
Configuration Parameters,
continued
TUNING
TAB, continued
Table 2-42 Tuning Tab Configuration Parameters,
continued
Properties Group Parameter Index# Parameter Description Value or Selection
Tuning
Constants,
continued
Reset
Minutes
or
Repeats
per Minute
2
Reset1
or
32
Reset2
RESET
(Integral Time) - adjusts
the controller’s output according
to both the size of the deviation
(SP-PV) and the time it lasts.
The amount of corrective action
depends on the value of Gain.
The reset adjustment is
measured as how many times
proportional action is repeated
per minute(
Repeats/minute
) or
how many minutes before one
repeat of the proportional action
occurs(
Minutes/repeat
).
0 or 0.02 to 50.00
0=OFF
Must be enabled
for PID-B or
DUP –B algorithm
selections
Rate
Minutes
1
Rate1
or
31
Rate2
RATE
action, in minutes affects
the controller’s output whenever
the deviation is changing; and
affects it more when the
deviation is changing faster.
0 or 0.1 to 10.00
minutes
0 = OFF
Feedforward
Gain
Feedforward
Gain
37 Applies Gain to the feedforward
value (FFV). Feedforward Input
is multiplied by this value.
0.0 to 10.0
Manual Reset Manual
Reset
26 MANUAL RESET- is only
applicable if you do not use
RESET (Integral Time)
Allows correction of output to
account for load changes to
bring the PV up to setpoint.
-100 to 100
(in % of Output)
