Function Blocks
Function Block Reference Guide 3/99178
2.59 SPEV Function Block,
continued
Outputs
E1 = Digital signal - segment event 1.
E2 = Digital signal - segment event 2.
E3 = Digital signal - segment event 3.
E4 = Digital signal - segment event 4.
E5 = Digital signal - segment event 5.
E6 = Digital signal - segment event 6.
E7 = Digital signal - segment event 7.
E8 = Digital signal - segment event 8.
E9 = Digital signal - segment event 9.
E10 = Digital signal - segment event 10.
E11 = Digital signal - segment event 11.
E12 = Digital signal - segment event 12.
E13 = Digital signal - segment event 13.
E14 = Digital signal - segment event 14.
E15 = Digital signal - segment event 15.
E16 = Digital signal - segment event 16.
Block Properties
Double click on the function block to access the function block properties dialog box.
Block Order (Read Only)
You can change the assigned execution order number by selecting “Execution Order” in the “Configure”
menu and arrange the order to suit your control strategy.
Continued next page
