Honeywell UMC800 Reference Guide

Function Blocks
3/99 Function Block Reference Guide 223
2.74 TPSC (3POS) Function Block,
continued
Configuration Parameters,
continued
TUNING
TAB, continued
Table 2-61 Tuning Tab Configuration Parameters,
continued
Properties Group Parameter Index# Parameter Description Value or Selection
Tuning
Constants,
continued
Reset
Minutes
or
Repeats
per Minute
2
Reset1
or
31
Reset2
RESET
(Integral Time) - adjusts
the controller’s output according
to both the size of the deviation
(SP-PV) and the time it lasts.
The amount of corrective action
depends on the value of Gain.
The reset adjustment is
measured as how many times
proportional action is repeated
per minute(
Repeats/minute
) or
how many minutes before one
repeat of the proportional action
occurs(
Minutes/repeat
)
0.02 to 50.00
Rate
Minutes
1
Rate1
or
30
Rate2
RATE
action
,
in minutes affects
the controller’s output whenever
the deviation is changing; and
affects it more when the
deviation is changing faster.
0 or 0.1 to 10.00
minutes
0 = OFF
