Function Blocks
3/99 Function Block Reference Guide 47
2.15 CARB Function Block,
continued
Table 2-11 General Tab Configuration Parameters,
continued
Properties Group Parameter Index# Parameter Description Value or Selection
Control,
continued
SP Tracking
N/A Setpoint Tracking
NONE
TRACK PV
When control
mode is “manual”, local
setpoint tracks process
variable.
TRACK RSP
When setpoint
is “remote setpoint”, local
setpoint tracks remote
setpoint.
Start/Restart Initial Mode
N/A
Control Mode and Setpoint
at NEWSTART
Newstart is the first scan
cycle following the cold start
of the controller
MAN LSP
Manual control
and last local
setpoint
AUTO LSP
Automatic control
and last local
setpoint.
AUTO RSP
Automatic control
and remote
setpoint.
MAN LSPonly
Manual control
and local setpoint
only.
AUTO LSPonly
Automatic
control and local
setpoint only*.
AUTO RSPonly
Automatic
control and
remote setpoint
only*.
*These modes will override the
configured POWER UP MODE.
Power Up
Mode
N/A
Control Mode and Setpoint
at power up
MAN LSP
Manual control and
last local setpoint
AM LSP
Same control mode
(auto or manual) and
last local setpoint.
AM LR Same control mode
(auto or manual) and
setpoint (local or
remote) as at power-
down.
Power Up
Out
N/A
Output at Power up
FAILSAFE
Failsafe output
value.
LAST OUT
Same as at
power down.
Failsafe Out Failsafe Out
16 Failsafe Output Value
-5 to 105%
